Timberfix 360 High Performance Wood Screws (Free Pozi Bit)

Timberfix 360 High Performance Wood Screws are premium, trade-grade structural woodscrews
designed for fast, secure fixing into softwood, hardwood and engineered timber.
With advanced self-cutting tips, lubricated, corrosion-resistant coating and
reinforced heads, Timberfix 360 screws are ideal for framing, decking, roofing, fencing,
carcassing, joists and general construction in C16/C24 and other timber classes.

Timberfix 360 High Performance Wood Screws are designed to outperform traditional
single- and twin-thread woodscrews in speed, grip and structural capability. Manufactured from
hardened steel with a specialist friction-reducing, anti-corrosion coating, they offer:

• High pull-out resistance thanks to deep, sharp threads,
• Reduced insertion torque due to lubricated surface and cutting tip,
• Clean countersinking with minimal splitting around the head.

The self-cutting (slash) tip bites quickly into timber and many board materials,
minimising or eliminating the need for pilot holes in softwoods, C16/C24 carcassing timbers and common sheet goods.
In dense hardwoods and very near edges, a pilot hole is still recommended to prevent splitting and ease driving.

Timberfix 360 screws are typically supplied with:

• A high-performance drive recess – commonly Torx/star or Pozi (check packaging) – for excellent
  bit engagement and fewer slipped screws.
• Under-head cutting ribs or a specially formed head to self-countersink into timber.
• A case-hardened core to resist snapping under high torque.

Available in a wide range of diameters and lengths, Timberfix 360 screws cover applications from
light interior studwork through to decking, roofing, fencing and heavy carcassing.

Typical Use Cases

• Timber framing & carcassing – fixing studs, rails, noggins and joists in C16/C24 framing.
• Decking & exterior carpentry – securing deck boards, joists, rails and balustrades
  (check coating/usage class for long-term external exposure).
• Roofing & structural work – fixing rafters, wall plates, purlins, trusses, hangers and straps
  where screws are specified.
• Fencing & landscaping – assembling fence rails, gates, sleepers and garden structures.
• General joinery & fit-out – fixing battens, pattresses, ledger boards and subframes
  to timber and plugged masonry.

Installation & Application Tips

• Choosing size & length:
  • As a rule of thumb, aim for 2.5–3 × the thickness of the thinner piece as penetration into the supporting timber.
  • Example: fixing 38 mm decking to a joist – use approx. 5.0 × 70–80 mm screws,
    depending on design and manufacturer guidance.
• Pilot drilling:
  • In softwood and most board materials, Timberfix 360 screws can usually be driven
    without pre-drilling, thanks to the self-cutting tip.
  • In hardwoods, near edges, or for end-grain fixings, drill a pilot hole
    approx. 80–90% of the screw’s core diameter to reduce splitting and driving torque.
• Driving the screw:
  • Use the correct driver bit for the head (e.g. Torx T20/T25 or Pozi PZ2 – check on the box).
  • Set your drill/driver or impact driver to a suitable torque setting to avoid overdriving.
  • Drive the screw so the head sits flush with or just below the surface; avoid over-sinking which can weaken the timber around the head.
• Using with wall plugs:
  • Timberfix 360 screws can also be used with appropriate nylon wall plugs in masonry where required.
  • Match screw gauge and length to plug manufacturer recommendations.
• Environmental exposure:
  • Standard coated Timberfix 360 screws are generally suitable for internal dry or sheltered applications.
  • Where long-term external or highly corrosive conditions are expected (e.g. exposed decking, coastal sites),
    use specifically rated exterior or stainless variants if offered in the range, or follow Timberfix guidance.

Technical & Performance Overview

Timberfix 360 High Performance Wood Screws are designed as advanced structural / construction woodscrews
suitable for use in modern timber engineering. For safety-critical structural applications, screws must be
selected and designed in line with Eurocode 5 (BS EN 1995) and the manufacturer’s technical data.

• Material: Case-hardened steel for high strength and resistance to snapping.
• Coating: Low-friction, corrosion-resistant coating (e.g. zinc or specialist polymer)
  to reduce driving torque and improve durability (exact finish – see packaging).
• Head type: Typically countersunk head with self-countersinking ribs beneath; some sizes may have reinforced or washer heads (check variant).
• Drive recess: Star/Torx or Pozi drive for secure bit engagement (exact type/size marked on box).
• Thread: Deep, sharp single or dual thread with cutting features for high pull-out resistance and faster insertion.
• Point: Self-cutting / slash / drill-point style to minimise pre-drilling in softwoods and boards.
• Available sizes: Wide range of diameters (e.g. 4.0–8.0 mm) and lengths
  (e.g. 30–300 mm, depending on variant – confirm on product listing).
• Substrates: C16/C24 softwood, many hardwoods, MDF, OSB, chipboard, plywood and use with suitable plugs in masonry.
• Usage class: Dependent on coating – typically suitable for Service Class 1 & 2 (internal dry/humid);
  use enhanced corrosion versions for Service Class 3 (external) where available.
• Standards & design: For load-bearing connections, design in accordance with BS EN 1995 (Eurocode 5)
  and seek Timberfix load data and, where necessary, structural engineer approval.
• Packaging: Supplied in trade boxes or tubs and mixed-size assortments for site use.

Timberfix 360 High Performance Wood Screws (Free Pozi Bit) Features & Customer Benefits

• Fast installation with fewer pilot holes
  Self-cutting tips and lubricated coating mean quicker driving and fewer snapped screws, particularly in C16/C24 carcassing.
• High load-bearing capability
  Hardened core and advanced thread design provide excellent pull-out and shear performance for structural timber fixings
  when correctly designed.
• Cleaner finishes without extra countersinking
  Under-head ribs help the screw self-countersink, saving time and giving a neater, flush finish on visible work.
• Reduced bit wear and cam-out
  High-quality drive recess and hardened heads give better bit engagement, improving productivity and reducing wasted screws.
• Versatile across many timber applications
  One screw range can handle framing, decking, roofing, fencing and general joinery, simplifying stock for contractors.

Frequently Asked Questions – Timberfix 360 High Performance Wood Screws (Free Pozi Bit)

1. Can I use Timberfix 360 screws in C16/C24 structural timber?

Yes. Timberfix 360 screws are designed for use in C16 and C24 softwood for structural and carcassing work.
However, for load-bearing structural joints you must:

• Design connections in accordance with Eurocode 5 (BS EN 1995), and
• Follow Timberfix technical data on characteristic values and recommended spacings/edge distances.

2. Do I always need to pilot drill?

Not in all cases:

• In softwoods and most board materials, the self-cutting tip usually allows installation without a pilot.
• In dense hardwoods, near edges, or where splitting is a risk, a pilot hole is recommended
  (approx. 80–90% of the core diameter).

3. Are Timberfix 360 screws suitable for external use?

It depends on the coating variant:

• Standard coated screws are generally intended for internal or sheltered applications (Service Class 1 & 2).
• For fully external, exposed conditions, use Timberfix 360 versions specifically rated for external use
  (e.g. heavy-duty or stainless steel variants), or follow manufacturer guidance.

4. What driver bit should I use?

Timberfix 360 screws typically use a star/Torx or Pozi drive, depending on size and batch. Check:

• The box label for the drive type and size (e.g. T20, T25, PZ2), and
• Use good-quality bits in good condition to minimise cam-out and damage to the recess.

5. Can I use Timberfix 360 screws with wall plugs in masonry?

Yes. They can be used as the screw component in a plug-and-screw fixing system:

• Select the correct plug size for the screw gauge,
• Drill the masonry hole to the correct diameter and depth for the plug, and
• Insert the plug, then drive the Timberfix 360 screw through the fixture into the plug.

6. Common Uses & How to Use Timberfix 360 High Performance Wood Screws (Free Pozi Bit)

Common Uses:

• Fixing stud walls, joists and rafters in timber frame construction.
• Securing decking boards and joists (with appropriate external-rated variants).
• Assembling fences, gates, pergolas and garden structures.
• Fixing battens, ledger boards and pattresses to timber and plugs.
• General carpentry, joinery and repair work.

How to Use – Step-by-Step:

1. Select the appropriate diameter and length for your materials and required embedment.
2. Where needed (hardwoods/edge fixings), drill pilot holes to the recommended diameter and depth.
3. Position and clamp the components to be fixed together.
4. Fit the correct driver bit into your drill or impact driver and set a suitable torque/clutch.
5. Drive the Timberfix 360 screw until the countersunk head is flush (or just below) the timber surface.
6. For visible work, fill or plug heads if a concealed appearance is required, then sand/finish as needed.
